Pentax 645 HD DA 28-45mm F/4.5 ED AW SR Lens

Image Stabilized LensImage Stabilized LensWeatherproof - Seals protect from dust, humidity and light splashing.Weatherproof - Seals protect from dust, humidity and light splashing.Zoom LensZoom LensRectilinear are normal lenses that show straight lines as straight lines.Rectilinear are normal lenses that show straight lines as straight lines.Thread size in milimeters for screw-on filters.Thread size in milimeters for screw-on filters.82Quick-Shift Autofocus, also called Direct Manual-Focus (DMF).Quick-Shift Autofocus, also called Direct Manual-Focus (DMF).

Lens Description

The Pentax 645 HD DA 28-45mm F/4.5 ED AW SR is an ultra-wide to normal zoom designed for cameras with a 645D (0.8X) sensor. This constant-aperture zoom covers a 28 to 45mm focal-range. It provides the same field of view as a 22.4-36mm lens on a Full-Frame camera. An optical Image Stabilization System built into this lens compensates for camera shake.

This 2X zoom lens focuses down to 40cm from the imaging plane, capturing subject with a maximum 0.21X magnification. The lens offers a Quick-Shift AF system which lets the user simply rotate the focus-ring to focus manually. While this lens is capable of AF, it does not have a built-in focus motor. It can only focus with a compatible camera body which features a mechanical AF-coupling.

The lens weighs 1.47kg. Its body is weatherproof against adverse weather such as rain and snow. Seals in key areas prevent entry of water and dust.

This lens is only available for the Pentax 645 mount. It directly attaches and is fully compatible with all Pentax 645 mount cameras with 645D (0.8X) sensors.

Pentax 645 HD DA 28-45mm F/4.5 ED AW SR
Buy from Amazon
Pentax 645 HD DA 28-45mm F/4.5 ED AW SR

Focal-Range

25mm90mm
28-45mm
FOCAL-RANGE OF WEATHERPROOF Pentax 645 MOUNT LENSES WITH AT LEAST 645D (0.8X) COVERAGE

Angle-Of-View

42.5°95°
63-89°
ANGLE OF VIEW OF WEATHERPROOF Pentax 645 MOUNT RECTILINEAR LENSES WITH 645D (0.8X)+ COVERAGE

Maximum Aperture

2.84.5
4.5
MAXIMUM APERTURE OF WEATHERPROOF Pentax 645 MOUNT LENSES WITH AT LEAST 645D (0.8X) COVERAGE

Viewing Angle Range

Pentax 28-45mm F/4.5

Maximum Aperture

Compared to other Pentax 645 645D (0.8X) lenses.
63-89°
Max F/4.5

Magnification

0.11X1X
0.21X
MAGNIFICATION OF Pentax 645 MOUNT LENSES WITH AT LEAST 645D (0.8X) COVERAGE

Weight

416g1470g
1470g
WEIGHT OF WEATHERPROOF Pentax 645 MOUNT LENSES WITH AT LEAST 645D (0.8X) COVERAGE

Pentax 645 HD DA 28-45mm F/4.5 ED AW SR Specifications

Brand Pentax Model 645 HD DA 28-45mm F/4.5 ED AW SR
Mount Pentax 645 Max FLM 0.8X
Focal Range 28 - 45mm View Angle 89 - 63°
Max ApertureF/4.5Min ApertureF/32
Min Focus40cmMagnification0.21X
Filter Size82mm Aperture Blades9
Size (D x L)99 x 152mm Weight1470g
TiltN / A ShiftN / A
Stabilization Built-In ProtectionWeatherproof
Zoom Drive Mechanic Focus Drive AF with Quick-Shift
Zoom Mechanism External Focus Mechanism External
Hood Bayonet Focus Motor External
Perspective RectilinearIntroduced2014-08-04
